1/2" Rod End Left Hand (20 TPI)

1/2" Rod End – Left Hand, 20 TPI

Heat-Treated Chromoly Heim Joint | 16,238 lb RSL | 1/2" Bore

This 1/2"-20 TPI left-hand Heim joint is built to take real-world abuse in suspension and steering systems where compact strength matters. It’s fully heat-treated chromoly and rated to a 16,238 lb radial static load — strong enough for UTVs, lightweight buggies, and performance street or track builds.

The housing is hard chrome plated, with a heat-treated 52100 bearing and a Teflon-impregnated nylon race for smooth movement and long service life. As a one-piece design, it’s not only stronger but simpler — fewer parts mean fewer points of failure when you're deep in the trail or in the middle of a race.

• Part Number: PN1669
• Thread: 1/2"-20 TPI (Left-Hand)
• Bore Size: 1/2"
• Material: Heat-treated chromoly housing, hard chrome finish
• Bearing: 52100 steel, heat-treated and hard chrome plated
• Race: Teflon-impregnated nylon
• Radial Static Load Rating: 16,238 lbs
• Use Case: UTVs, lightweight link systems, steering and suspension
• Made in the USA
• Sold individually

Only use Tri-Flow to service these rod ends. WD-40, Blaster, or similar products will damage the liner and void the warranty.
